Please Contact Us to Order to offer competitive prices and delivery time for ABP-Antriebstechnik GmbH - 307200 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Germany Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | ABP-Antriebstechnik GmbH |
| Product | 307200 |
| Internal code | IMP2007412 |
| Weight | 0.09 |
| Technical specification | Doppelschlaufenkupplung 4848, 48 x 48 mm, iD 6 - 14 mm, H8 Toleranz Aussendurchmesser: 48 mm Bohrung d1: 6 mm 8 mm 9.5 mm 10 mm 12 mm 14 mm Bohrung d2: 6 mm 8 mm 9.5 mm 10 mm 12 mm 14 mm Toleranz: H8 Temperaturbereich: -30 / +80 °C Befestigungsart: schrauben Drehfedersteife: 28 Nm/rad Radialfedersteife: 7 N/mm Trägheitsmoment: 106 gcm² Werkstoff Flansch: Stahl verzinkt Werkstoff Schlaufe: Polyurethan max. Drehzahl: 3.000 RPM max. Drehmoment: 2 Nm max. Wellenversatz: Radial +- 3 mm Axial +- 4 mm Angular +- 12 Grad max. M. Schrauben: 100 Ncm Gewicht ca.: 85 g Versandgewicht: 0,12 Kg Artikelgewicht: 0,09 Kg |
