Discover the superior quality and performance of the Leser 4884.8852 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The 4884.8852 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of 4884.8852 :
At Impexron GMBH , we offer the 4884.8852 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the 4884.8852 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Leser products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 4884.8852 by Leser in Germany?
You can purchase 4884.8852 by Leser from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.
What is the price of the 4884.8852?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Leser in Germany?
While we are not the official distributor or seller of Leser in Germany, we source our products from reliable channels and offer you original Leser equipment at competitive prices.
How can I access 4884.8852 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 4884.8852 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 4884.8852?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Leser |
| Product | 4884.8852 |
| Description | Clean service safety valve, type 488 |
| Internal code | IMP4304434 |
| Weight | 12.6 |
| Custom code | 84814010 |
| Technical specification | hyTight, for great performance, closed spring cover, gastight cap H2, for vapors, gases and liquids Technical specification: Ordercode output, line 1: H03M53N04X00I81A25L96L97H02B69 Ordercode output, line 2: J23H01J85H87A87 Housing material: (H02) 1.4404/316L NPS 2" nominal input NPS 3" nominal outlet Pressure level entry PN 16 Pressure level outlet PN 16 d0 (ASME DIN) [mm] 37.0 outflow rate D/G: 0.70 flow rate F: 0.45 Connection entry (L96) CO - clamp connection /ISO 2852/ ISO 2037 Port Outlet (L97) CO - clamp connection /ISO 2852/ ISO 2037 pipe standard entry (H87) according to ISO 2037/ ASME BPE Pipe standard outlet (A87) according to ISO 2037/ ASME BPE Clamp size inlet/inner diameter 48.6 mm Clamp size inlet/outside Ø 64.0 mm Clamp size outlet /inner diameter 72.9 mm Clamp Dimension Outlet/ Outside Diameter 91.0 mm Response pressure: 0.25 Pressure unit: mpa-G Response pressure [bar-g] 2.50 Response pressure in psi-g: 36.26 Cold setting pressure [bar-g] 2.50 Cold setting pressure [psi-g] 36.26 Operating temperature: 138 Temperature unit: °C - centigrade Operating temperature [°C] 138.00 Operating temperature in °F: 280 Surface package READER: (B69) hyClean finish Medium wetted surface: Inlet: electropolished Ra <= 0.75μm Bottom plate: electropolished Ra <= 0.75μm Blowout room surface: Inner surface: electropolished Ra <= 1.5μm Weld seam: electropolished Ra <= 3μm Outer surface: electropolished Ra <= 1.5μm Soft sealing plate: (J23) with soft seal FKM “L” (Viton, Fluorel, Technoflon) Valve treatment: (J85) Oil and grease-free cleaning for standard requirements (not for oxygen), incl. white light test Material quality certificate for: (H01) Housing — item 1 with material quality certificate 3.1 according to DIN EN 10204 Documentation: (H03) READER CGA Certificate for Global Application Acceptance Test Certificate 3.1 according to DIN EN 10204 Documentation: (M53) Acceptance test certificate 3.1 according to DIN EN 10204: Oil and grease free test acc. LGS 0210 Documentation: (N04) Test report special surfaces center roughness value Ra Tag no., valve 1: SV-41005 Type and location of the day no.: (M25) Tag with tag (foil/paper) 3.Marking, pos.: Set P.: 0.25 mpa-G Type and location of 3rd code: (M16) World shield marking 1st line General notes Design according to reader serial no.: 10676136, deviating with a response pressure of 0.25 mpa-G |
