Discover the superior quality and performance of the HIMMEL CF10-M1C6/4 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The CF10-M1C6/4 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of CF10-M1C6/4 :
At Impexron GMBH , we offer the CF10-M1C6/4 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the CF10-M1C6/4 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply HIMMEL products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy CF10-M1C6/4 by HIMMEL in Germany?
You can purchase CF10-M1C6/4 by HIMMEL from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.
What is the price of the CF10-M1C6/4?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of HIMMEL in Germany?
While we are not the official distributor or seller of HIMMEL in Germany, we source our products from reliable channels and offer you original HIMMEL equipment at competitive prices.
How can I access CF10-M1C6/4 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CF10-M1C6/4 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CF10-M1C6/4?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | HIMMEL |
| Product | CF10-M1C6/4 |
| Description | worm gear motor |
| Internal code | IMP3590776 |
| Weight | 12 |
| Custom code | 85015100 |
| Technical specification | 2010000186 HIMMEL® worm gear motor CF10-M1C6/4 Dimension sheet: CF14/1168 Gearbox design/Type: HIMMEL® worm gear motor/HIMMEL® -worm gear motor Transmission Type/ Type: CF10-M1C6/4 Dimension sheet: CF14/1168 Output speed/ Output speed [1/min; rpm]: 6.10/9.20//7.30/11.10 Translation/Ratio [i]: 157.87 Color/colour: RAL 7011 Iron Grey 2K/Iron Grey 2K-PUR Corrosivity category/corrosion protection: C1: i.a.A. DIN EN ISO 12944-2/HN716.21 Paint layer thickness [μm]: 60-80 Protection class: IP54 Design/mounting position: B5-00-B Output torque/Output torque [Nm]: 55.1/48.±45.6/40.1 Direction of rotation: left/left [CCW] Output shaft transmission/ Output shaft [mm; inch]: V20x35 Gearbox bearing: assigned bearings Oil type: CLP PG 460 Synth.oil Oil quantity [l]: 0.18 Flange diameter/Flange diameter [mm; inch]: 120 Shaft material/Shaft material: ST60-2 Gearbox sealing/Sealing: shaft seal ring (WDR)/shaft seal ring Label/Approval|Identification/Certification: CE Number of poles/poles: 6/4 Rated frequency/ Nominal frequency [Hz]: 50//60 Rated voltage/nominal voltage [V]: 380/380//440/440 Circuit/ Wiring: S302//S302 (Y/Y//Y/Y) Rated power/nominal power [kW]: 0.09/0.12//0.09/0.12 Rated engine speed/Motor speed nom. [1/min; rpm]: 960/1460//1160/1760 Rated current/Nominal current In [A]: 0.55/0.65//0.40/0.45 CosPhi/CosPHI: 0.67/0.67 KK location/Terminal box position: 1A KK version/Terminal box type: plastic/plastic Winding protection/Motor protector: ohne/without Motor output shaft/Output shaft [mm; inch]: V11x24.5 Sealing motor/Sealing motor: normal/normal Insulation class: F Operating mode/Duty type: S1 Fan/Fan: plastic/plastic |
