Please Contact Us to Order to offer competitive prices and delivery time for Galltec Mela - KKC3.Ex/8 Humidity/temperature sensor explosion number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Germany Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | Galltec Mela |
| Product | KKC3.Ex/8 |
| Description | Humidity/temperature sensor explosion |
| Internal code | IMP323401 |
| Weight | 0.47 |
| Custom code | 90258040 |
| Technical specification | II 1/2 G Ex ia IIC T4 Ga/Gb II 2 D Ex ia IIIC T95°C Db -40°C Ta +80°C Approved for use in potentially explosive areas according to EC type examination certificate IBEXU 07 ATEX 1114 Use in zone 0 only together with ZA40 mounting kit (Please order ZA40 mounting kit separately, further assembly instructions and dimensional diagrams according to data sheet C4.8) Die-cast aluminium housing Ex IP66 Stainless steel sensor tube 1.4301, length: 232 mm Sewer assembly Output 1: relative humidity Output range1:0... 100 %rF Output signal 1:4... 20 mA Output 2: temperature Output range2: -20... 80° Output signal 2:4... 20 mA Operating voltage: 13... 24 V DC Intrinsically safe Operating temperature range: -40... 80 °C Filter: ZE13 stainless steel sintered metal filter |
