Discover the superior quality and performance of the Kobold PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 with Impexron GMBH in Germany . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 :
At Impexron GMBH , we offer the PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 at competitive prices and with the fastest delivery times across Germany . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose Impexron GMBH ?
Get Your Quote Today! Ready to enhance your operations with the PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Kobold products, Impexron GMBH is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 by Kobold in Germany?
You can purchase PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 by Kobold from Impexron GMBH. We serve customers across Germany, offering competitive prices and reliable service.
What is the price of the PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 ?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Kobold in Germany?
While we are not the official distributor or seller of Kobold in Germany, we source our products from reliable channels and offer you original Kobold equipment at competitive prices.
How can I access PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 ?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Kobold |
| Product | PIT-S206R026H-0302-L-K / UMF2-D14G0BK3 |
| Description | magnetic inductive flowmeter |
| Internal code | IMP554530 |
| Weight | 1 |
| Technical specification | Electro-Magnetic-Flowmeter Model-Code Sensor : PIT-S206R026H-0302-L-K Model-Code Transmitter : UMF2-D14G0BK3 Function Measuring principle : pulsed DC field Operating conditions Flow range [m3/h] : inner diameter needed Fluid : fluid Density [kg/m3] : 1000 Operating temp. [°C] : max. 100 Operating press. [bar g] : max. 16 Flow direction : - please state Sensor informations Wetted parts : SS 1.4571/1.4404/PTFE Process connection : 2" CLASS 150 RF ASME B16.5 Nominal pressure : 16 bar Sensor length "T" : 263 mm (DN700-DN1200) Electrodes : Hastelloy C-4 Earthing electrode : without Ingress protection : IP65 Connection to sensor : separate - terminal box via M20x1,5 Approval : without Fluid temperature limit : 100 °C Staight inlet run : 10 x DN Straight outlet run : 5 x DN Transmitter informations (UMF2) Mounting : separate (-40°C to 100°C Med. temp.) Ingress protection : IP67 Conduit port opening : M20x1,5 Approval : without Explosion proof : without Display : LCD Power supply : 24V DC (+20/-10%) Current output : 4-20 mA with HART®-Protocol Pulse output : passive 24V DC Status output : passive 24V DC forward-/backward flow detection MIN/MAX flow, alarm Ambient temperature : -20 bis 60°C Performance characteristics Accuracy : +/- 1,5% of actual flow +/- 0,5% of full scale Min. conductivity min : 20 μS/cm (100 μS/cm with empty pipe detection) Accessories : - with special coils for low velocities of 0,5 -5 m/s - 15 m cable IP67 incl. junction-box on transmitter - including test-report 2.2 |
