Please Contact Us to Order to offer competitive prices and delivery time for SUN-Control - WT205N Water-Trap number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Germany Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
| BRAND | SUN-Control |
| Product | WT205N |
| Description | Water-Trap |
| Internal code | IMP3398320 |
| Weight | 2 |
| Custom code | 84219990 |
| Technical specification | Water-Trap WT 20.5 N, terminal both sides 1/8” NPT-external thread Country of origin: Germany Water pressure membrane: 0 - 2 bar Operating pressure for gas: 0 - 2 bar Gas flow: 0 - 400 l air/h Pressure drop at 100 l air/h: approx. 10 mbar Pressure drop at 400 l air/h: approx. 40 mbar Diaphragm pore size: < 0,1μm Operating temperature: 0°C to +90°C Effective filter area: 25 cm2 Housing volume: 5 ml Materials used: PTFE, PP, SUN-C coating Dimensions: Diameter 70 mm, length 120 mm Gas connections: on both sides 1/8“ NPT outside thread or on both sides 6 mm pipe nozzle or on both sides 6-12 mm stepped hose barb |
